WIRE TONGS Wire tongs are usually used in pairs with supporting accessories to support and move ener- gized conductors away from the work area for replacement of insulators, cross arms, poles and hardware. FEATURES AND BENEFITS: • Metal components are heat treated aluminum alloy or bronze alloy • Conductor jaws are interlocking to keep conductor positively engaged • Two conductor head sizes are available to accommodate a wide range of conductor sizes • Acme threads facilitate tightening of head MEDIUM HEAD 3/16” TO 2” WIRE LARGE HEAD 5/8” TO 2 1/2” WIRE CAT NO SIZE LBS CAT NO SIZE LBS 5679-8 1 1/2” x 8’10” 5.5 5315-8 1 1/2” x 8’10” 7.0 5679-10 1 1/2” x 10’10” 6.3 5315-10 1 1/2” x 10’10” 7.8 5671-8 2” x 8’10” 7.5 5320-8 2” x 8’10” 9.0 5671-10 2” x 10’10” 8.5 5320-10 2” x 10’10” 10.0 5671-12 2” x 12’10” 9.6 5320-12 2” x 12’10” 12.1 5672-10 2 1/2” x 10’10” 14.4 5325-10 2 1/2” x 10’10” 15.9 5672-12 2 1/2” x 12’10” 16.1 5325-12 2 1/2” x 12’10” 17.6 5672-14 2 1/2” x 14’10” 18.1 5325-14 2 1/2” x 14’10” 19.6 5672-16S* 2 1/2” x 16’10” 22.3 ----- ----- ----- 5673-12 3” x 12’10” 20.2 5330-12 3” x 12’10” 21.7 5673-14 3” x 14’10” 22.7 5330-14 3” x 14’10” 24.2 *POLE IS DESIGNED WITH METAL SPLICE IN CENTER Medium head has spring loaded latch which makes installation of wire tong safe and easy. The weight of the tool closes the latch on the conductor. The wire tong is then tightened to secure conductor into position. CONDUCTOR AND PERSONNEL SUPPORTS Phone: 269.945.9541 • Fax: 269.945.4623 • www.hfgp.com • Email: hastings@hfgp.com PO Box 218, 1301 W Green Street, Hastings, Michigan 49058-0218 These products are for trained professionals only. 07/18 300
